HFS-864 342 700 A 28643 F716 - INGUN Industrial Spare Part for RFQ
The HFS-864 342 700 A 28643 F716 is an original INGUN industrial component available through AltraParts for RFQ-based sourcing. For contacting plug connectorsUp to 7.5 GHzCable interface SMAInstallation via flange mounting
Key Features
- Original INGUN product reference for professional industrial applications
- Suitable for electronic testing, fixture systems, PCB test, ICT/FCT, or connector test environments
- RFQ-based sourcing for availability, lead time, and quantity quotation
- International supply support with export and customs documentation assistance
Product Information
| Brand |
INGUN |
| SKU / Part Number |
HFS-864-0001 |
| Series |
HFS 864 |
| Supply Model |
Request for Quote |
| Application |
Industrial test equipment and electronic test components |
Technical Data
| Barrel diameter |
22 mm [.866 in] |
| Compatible assembly interface gender |
M signal conductor male / pin |
| Continuous plunger |
Yes |
| DUT / contact |
7/16 |
| DUT interface gender |
F signal conductor female / socket |
| Exchangeable inner conductor |
No |
| Exchangeable outer conductor |
No |
| Floating mount |
Yes |
| Frequency range up to |
7.5 GHz |
| Grid |
23.5 mm [925 mil] |
| Impedance |
50 Ohm |
| Inner conductor max. current load capacity |
3 A |
| Inner conductor maximum stroke |
4 mm [.157 in] |
| Inner conductor tip style |
42 flat with bore |
| Inner conductor tip style diameter |
7 mm [.275 in] |
| Inner conductor tip style material |
3 CuBe |
| Inner conductor tip style surface |
A gold |
| Inner conductor working stroke |
2 mm [.078 in] |
| Installation height without receptacle |
28.9 mm [1.13 in] |
| Installation type |
Flange |
| Interface of compatible assembly |
SMA 50 Ohm |
| Max. temperature |
80 °C [176 °F] |
| Min. temperature |
-40 °C [-40 °F] |
| Non-rotating |
No |
| Number of inner conductors |
1 |
| Outer conductor max. current load capacity |
10 A |
| Outer conductor maximum stroke |
5 mm [.196 in] |
| Outer conductor tip style |
43 centring for outer side of connector |
| Outer conductor tip style diameter |
21 mm [.826 in] |
| Outer conductor working stroke |
4 mm [.157 in] |
| Product group |
HFS radio-frequency test probes |
| Recommended torque at interface |
45 cNm [3.98 lbf·in] |
| RoHS-compliant |
Yes |
| Series |
HFS-864 |
| Spring force of each inner conductor at working stroke |
5 N [17.9 ozf] |
Request a Quote
Send us the INGUN part number, required quantity, and delivery country. AltraParts will review availability, lead time, pricing, and shipping options for your RFQ.
