HSS-150 303 400 A 3002 - INGUN Industrial Spare Part for RFQ
The HSS-150 303 400 A 3002 is an original INGUN industrial component available through AltraParts for RFQ-based sourcing. Trusted, robust high-current probes, optimally sized for current load capacity ratioLow-Ohm probe with Ri typical: < 10 mOhmFor use in function and burn-in testsLarge selection of tip styles and spring forces for optimum contact with DUTOptimum adjust…
Key Features
- Original INGUN product reference for professional industrial applications
- Suitable for electronic testing, fixture systems, PCB test, ICT/FCT, or connector test environments
- RFQ-based sourcing for availability, lead time, and quantity quotation
- International supply support with export and customs documentation assistance
Product Information
| Brand |
INGUN |
| SKU / Part Number |
HSS-150-0004 |
| Series |
HSS 150 |
| Supply Model |
Request for Quote |
| Application |
Industrial test equipment and electronic test components |
Technical Data
| Adjustable installation height |
No |
| Barrel diameter |
3.5 mm [.137 in] |
| Collar height |
02 |
| Compatible receptacle(s) |
KS-150 |
| Contacting from |
Post , Pin |
| Current load capacity / rated current |
50 A |
| Grid |
5.08 mm [200 mil] |
| Installation type |
Plug-in |
| Magnetic |
Yes |
| Max. temperature |
200 °C [392 °F] |
| Maximum stroke |
5.5 mm [.216 in] |
| Min. temperature |
-100 °C [-148 °F] |
| Non-rotating |
No |
| Product group |
High-current test probe , Standard HSS (press-in) |
| Quick-exchange system |
Yes |
| RoHS-compliant |
Yes |
| Series |
HSS-150 |
| Spring force at working stroke |
3 N [10.7 ozf] |
| Spring pre-load |
1.31 N [4.71 ozf] |
| Sub-product group |
Standard HSS (press-in) |
| Tip diameter |
4 mm [.157 in] |
| Tip style |
03 inverse cone |
| Tip style material |
3 CuBe |
| Tip style surface |
A gold |
| Total length |
38.5 mm [1.51 in] |
| Typical resistance (Ri) |
10 mOhm |
| Working stroke |
4.4 mm [.173 in] |
Request a Quote
Send us the INGUN part number, required quantity, and delivery country. AltraParts will review availability, lead time, pricing, and shipping options for your RFQ.
