• INGUN SKS-215-0205 Industrial Test Component INGUN industrial spare part RFQ

INGUN

INGUN SKS-215-0205 Industrial Test Component

SKU SKS-215-0205
Price on request (RFQ)
30-day return policy EU: 14-day right of withdrawal info@altraparts.com RFQ by email with files
Why is there no price on this page? Price and lead time for this reference depend on quantity, delivery country and the supplier stock reviewed at that moment, so a fixed list price would be misleading. Send the reference and quantity — availability, compatible alternatives, lead time and shipping options are confirmed in writing after RFQ review.
E-mail the sourcing desk
info@altraparts.com Send by e-mail

Reply in writing, usually within hours. Attach the label photo, quantity and delivery country.

INDUSTRIAL PROCUREMENT FILE

Part Sourcing Brief

This item can be reviewed for industrial spare parts sourcing, replacement, maintenance, repair, and MRO procurement requirements.

Manufacturer / Brand INGUN
Product Reference SKS-215-0205
Request Type Industrial replacement part sourcing
Quote Review Includes Availability, lead time, alternatives, shipping

Recommended RFQ details

  • Required quantity
  • Delivery country
  • Photos, label, nameplate, or technical document if available
Start Sourcing Request

Quote, lead time, alternatives, and shipping options are confirmed after technical RFQ review.

INGUN SKS-215-0205 Industrial Test Component INGUN industrial spare part RFQ

SKS-215 305 064 A 1502 M - INGUN Industrial Spare Part for RFQ

The SKS-215 305 064 A 1502 M is an original INGUN industrial component available through AltraParts for RFQ-based sourcing. For a wide range of applications: performs components detection check, is a switch for detecting closed/open states, and a signal transmitter for process controlVarious collar heights are available on the receptacles to adjust the installation heightThe…

Key Features

  • Original INGUN product reference for professional industrial applications
  • Suitable for electronic testing, fixture systems, PCB test, ICT/FCT, or connector test environments
  • RFQ-based sourcing for availability, lead time, and quantity quotation
  • International supply support with export and customs documentation assistance

Product Information

Brand INGUN
SKU / Part Number SKS-215-0205
Series SKS 215 M
Supply Model Request for Quote
Application Industrial test equipment and electronic test components

Technical Data

Adjustable installation height Yes
Barrel diameter 1.65 mm [.064 in]
Collar height 02
Compatible connector(s) SE-081
Compatible receptacle(s) KS-215 M
Contacting from Pad , Female connector
Current load capacity / rated current 3 A
Grid 2.54 mm [100 mil]
Installation type Screw-in
Magnetic Yes
Max. temperature 80 °C [176 °F]
Maximum stroke 5 mm [.196 in]
Min. temperature -40 °C [-40 °F]
Non-rotating No
Product group SKS (screwed-in) , Switching probes
Quick-exchange system No
RoHS-compliant Yes
Screw-in torque 3 – 5 cNm [.265 – .442 lbf·in]
Screw-in torque max. 5 cNm [.442 lbf·in]
Screw-in torque min. 3 cNm [.265 lbf·in]
Series SKS-215 , SKS-215 M plug system, screw-in
Spring force at switching point 0.45 N [1.61 ozf]
Spring force at working stroke 1.5 N [5.39 ozf]
Spring pre-load 0.25 N [.899 ozf]
Sub-product group SKS (screwed-in)
Switching point 8.5 mm [.334 in]
Switch path 1.5 mm [.059 in]
Tip diameter 0.64 mm [.025 in]
Tip style 05 bullet-nosed (full radius)
Tip style material 3 CuBe
Tip style surface A gold
Total length 46.5 mm [1.83 in]
Type of test probe connection Plug
Working stroke 4 mm [.157 in]

Request a Quote

Send us the INGUN part number, required quantity, and delivery country. AltraParts will review availability, lead time, pricing, and shipping options for your RFQ.
